FE Civil Practice Question Solution included after investigation
CASE E-042 Β· FE

The Beam Reactions That Refused to Split 50-50

The total load was 28 kN, but the support reactions were not 14 kN each.

β–Ά INTERACTIVE CASE FILE β€’ 5–10 MIN β€’ CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-042 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field β€” in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A simply supported 6 m beam has a pin at A and a roller at B. An 8 kN downward load acts 1 m from A, and a 20 kN downward load acts 4 m from A. A quick check assigns 14 kN to each support because the total load is 28 kN. Calculate the actual reactions and identify why the equal split is incorrect.

Statics Civil Design Verification Root Cause Analysis Safe Correction
E-042
INVESTIGATION WORKSPACE WORK THROUGH THE CASE β€” YOUR CHOICES MATTER.
πŸ”’
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

πŸ”’Root causeComplete the case
to reveal
πŸ”’Correct fixComplete the case
to reveal
πŸ”’Exam takeawayComplete the case
to reveal
CASE CLOSED Β· ENGINEERING VERDICT

What actually failed β€” and what should change.

What failed

The reaction split was based only on total force.

What was missed

The loads create unequal moments about the supports.

Corrected model

Use Ξ£F=0 and Ξ£M=0 on the complete beam free-body diagram.

QUICK ANSWER

For a 6 m simply supported beam with 8 kN at 1 m and 20 kN at 4 m from A, moment equilibrium about A gives RB(6)=8(1)+20(4)=88, so RBβ‰ˆ14.67 kN. Vertical equilibrium then gives RAβ‰ˆ13.33 kN.

ENGINEERING TAKEAWAY

Use both force equilibrium and moment equilibrium. Load location controls the reaction distribution.

CASE QUESTIONS

Questions this case should settle.

Do simply supported beam reactions always split equally?

No. Equal reactions occur only for appropriate symmetric loading.

Why take moments about a support?

It removes that support reaction from the moment equation and lets the other reaction be solved directly.
