FE Civil Practice Question Solution included after investigation
CASE E-044 · FE

The Floor Beam That Was Loaded at 400 lb/ft, Not 50

The floor load was 50 psf. The beam did not carry 50 lb/ft—it carried 400 lb/ft.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-044 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

An interior floor beam supports a uniform floor load of 50 psf. Adjacent beams are spaced 8 ft apart, so the beam's tributary width is 8 ft. A calculation applies 50 lb/ft directly to the beam. Determine the correct line load and identify the unit/load-path mistake.

Structural Engineering Civil Design Verification Root Cause Analysis Safe Correction
E-044
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

A 50 psf floor load was applied as 50 plf.

What was missed

The beam collects load across an 8 ft tributary width.

Corrected model

Use w=q×tributary width and verify dimensions.

QUICK ANSWER

For an interior beam supporting an 8 ft tributary width under a 50 psf floor load, the beam line load is 50×8=400 lb/ft. The tributary width converts force per area into force per length.

ENGINEERING TAKEAWAY

Convert area load to line load using tributary width: w_line = q_area × tributary width.

CASE QUESTIONS

Questions this case should settle.

How do you convert psf to plf on a beam?

Multiply the area load by the beam's tributary width.

What line load comes from 50 psf over 8 ft tributary width?

400 lb/ft.
