FE Civil Practice Question Solution included after investigation
CASE E-045 · FE

The Beam Moment That Peaked at 75 kip-ft, Not 300

The total load was 30 kips. Multiplying by half the span produced the wrong bending moment.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-045 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A 20 ft simply supported beam carries a uniform load of 1.5 kip/ft over the entire span. A design note multiplies the total 30 kip load by 10 ft and reports 300 kip-ft maximum moment. Determine the correct maximum bending moment and identify what the 300 kip-ft calculation omitted.

Structural Engineering Civil Design Verification Root Cause Analysis Safe Correction
E-045
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

The external load moment about one support was mistaken for internal maximum bending moment.

What was missed

Support reactions and section equilibrium.

Corrected model

For a simple beam under full-span UDL, Mmax=wL²/8.

QUICK ANSWER

For a simply supported beam carrying a uniform load over the full span, Mmax=wL²/8. With w=1.5 kip/ft and L=20 ft, Mmax=1.5×20²/8=75 kip-ft at midspan.

ENGINEERING TAKEAWAY

For a simply supported beam with uniform load over the full span, Mmax=wL²/8 at midspan.

CASE QUESTIONS

Questions this case should settle.

What is the maximum moment formula for a simply supported beam with full-span UDL?

Mmax=wL²/8.

Where does maximum moment occur for symmetric full-span UDL?

At midspan, where shear is zero.
