The AM Signal Whose Envelope Pinched Shut

The carrier was 5 V. The message amplitude was 6 V. The envelope detector stopped reproducing the message cleanly.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-035 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A conventional AM transmitter uses a 5 V carrier amplitude and a 6 V sinusoidal message amplitude. The technician expects the stronger message to improve the received audio, but an envelope detector produces severe distortion. Diagnose the modulation setting, calculate the modulation index, and choose a correction that restores valid envelope detection.

Communications Electrical & Computer Design Verification Root Cause Analysis Safe Correction
E-035
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

The envelope detector produced distortion.

What was assumed

More message amplitude was assumed to be always beneficial.

Corrected model

Check m=Am/Ac and keep m≤1 for conventional AM envelope detection.

QUICK ANSWER

For single-tone conventional AM, the modulation index is m=Am/Ac. With a 6 V message and 5 V carrier, m=1.2, or 120%. Because m>1, the AM envelope is overmodulated and simple envelope detection produces distortion.

ENGINEERING TAKEAWAY

For standard AM with envelope detection, keep 0≤m≤1. The modulation index is m=Am/Ac for a single-tone message.

CASE QUESTIONS

Questions this case should settle.

What is the modulation index for Am=6 V and Ac=5 V?

m=6/5=1.2, or 120%.

When does conventional AM become overmodulated?

When the modulation index exceeds 1.
