FE Electrical & Computer Practice Question Solution included after investigation
CASE E-026 Β· FE

The Protection Diode That Starved the 5 V Sensor

The reverse-polarity protection worked, but the 5 V sensor would not start.

β–Ά INTERACTIVE CASE FILE β€’ 5–10 MIN β€’ CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-026 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field β€” in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A 5.0 V source feeds a sensor through a series silicon diode for reverse-polarity protection. The sensor requires at least 4.5 V to start. With a 0.7 V forward-drop model, only 4.3 V reaches the sensor.

Electronics Electrical & Computer Design Verification Root Cause Analysis Safe Correction
E-026
INVESTIGATION WORKSPACE WORK THROUGH THE CASE β€” YOUR CHOICES MATTER.
πŸ”’
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

πŸ”’Root causeComplete the case
to reveal
πŸ”’Correct fixComplete the case
to reveal
πŸ”’Exam takeawayComplete the case
to reveal
CASE CLOSED Β· ENGINEERING VERDICT

What actually failed β€” and what should change.

What was missed

Treating every conducting diode as a zero-volt ideal short.

Corrected model

With the 0.7 V constant-drop model, the resistor sees 4.3 V, so current is 4.3 mA, not 5 mA.

QUICK ANSWER

A forward-biased silicon diode modeled with a 0.7 V drop leaves about 4.3 V from a 5.0 V source, which can violate a 4.5 V sensor minimum.

ENGINEERING TAKEAWAY

Check the device model and operating region first, then apply the corresponding circuit equation.

CASE QUESTIONS

Questions this case should settle.

Why does a forward-biased silicon diode branch carry less current than an ideal-short model predicts?

With the 0.7 V constant-drop model, the resistor sees 4.3 V, so current is 4.3 mA, not 5 mA.
