FE Electrical & Computer Practice Question Solution included after investigation
CASE E-022 Β· FE

The Transfer Function That Settled at 5, Not 20

The numerator says 20. The unit-step output settles at 5. The model is working exactly as written.

β–Ά INTERACTIVE CASE FILE β€’ 5–10 MIN β€’ CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-022 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field β€” in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A stable first-order system has transfer function H(s) = 20/(s + 4). A technician applies a unit-step input and expects the output to settle at 20 because the numerator is 20. The measured output instead settles at 5. Determine the DC gain, relate the pole to the time constant, and modify the numerator so the same pole gives a steady-state output of 2 for a unit-step input.

Linear Systems Electrical & Computer Design Verification Root Cause Analysis Safe Correction
E-022
INVESTIGATION WORKSPACE WORK THROUGH THE CASE β€” YOUR CHOICES MATTER.
πŸ”’
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

πŸ”’Root causeComplete the case
to reveal
πŸ”’Correct fixComplete the case
to reveal
πŸ”’Exam takeawayComplete the case
to reveal
CASE CLOSED Β· ENGINEERING VERDICT

What actually failed β€” and what should change.

What caused the mismatch

The numerator 20 was mistaken for the DC gain; the actual gain is 20/4 = 5.

What was missed

The denominator must also be evaluated at s = 0 when finding DC gain.

Corrected model

Use H(0) for DC gain and pole location for response speed; for this system Ο„ = 0.25 s.

QUICK ANSWER

For a stable transfer function, the DC gain is H(0), not simply the numerator. For H(s) = 20/(s + 4), H(0) = 20/4 = 5, so a unit-step output settles at 5. The pole at -4 gives a 0.25 s time constant.

ENGINEERING TAKEAWAY

For a stable system, evaluate the transfer function at s = 0 to obtain DC gain, or use the final value theorem with the actual input. The pole at -4 sets a 0.25 s time constant independently of the DC gain scaling.

CASE QUESTIONS

Questions this case should settle.

How do you find the DC gain of a transfer function?

Evaluate the transfer function at s = 0, provided the relevant final value exists for the stable system.

What is the DC gain of 20/(s+4)?

H(0) = 20/4 = 5.

What time constant corresponds to a pole at -4?

For a first-order pole at -a, Ο„ = 1/a, so Ο„ = 0.25 seconds.
