A 'passband' tone reached the cutoff and lost nearly 30% of its amplitude.
Inspect, commit, prove, fix, and sign off.
Follow the investigation process used in the field โ in five guided steps.
Review the problem, diagram, and evidence.
Choose your hypothesis.
Run calculations and test your idea.
Select and validate a safe correction.
See the full debrief and key takeaways.
A first-order RC low-pass is specified with fc = 1.0 kHz. A 1.0 kHz, 2.00 V peak sensor tone is expected to pass almost unchanged, but the measured output is about 1.41 V peak. Diagnose the missing amplitude and choose a higher cutoff that keeps at least 90% of the 1 kHz amplitude.
Find the root cause, confirm the fix, and see how this connects to the exam.
A 2.00 V peak input became about 1.414 V peak at 1 kHz.
The cutoff frequency is already the -3 dB point.
Use the magnitude response to place fc according to allowed attenuation.
For a first-order RC low-pass, the cutoff frequency is the -3 dB point. At f = fc, |H| = 1/sqrt(2) โ 0.707, so a 2.00 V peak input becomes about 1.414 V peak.
Treat cutoff as the -3 dB point, not a zero-loss boundary. Use |H| = 1/sqrt(1+(f/fc)^2) and choose fc from the allowed amplitude loss.
About 0.707, or -3 dB.
Because power is proportional to amplitude squared, so 0.707ยฒ is about 0.5.
Place the cutoff sufficiently above that frequency based on the allowed magnitude loss.
