FE Industrial & Systems Practice Question Solution included after investigation
CASE E-089 · FE

The Part That Lost $45, Not $60

Quality loss did not grow linearly with deviation from target. Under the Taguchi quadratic model, a 3-unit deviation caused a $45 loss.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-089 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A quality characteristic has target T=100 units. A deviation of 4 units from target is associated with an $80 quality loss. Assume the Taguchi loss function L=k(y-T)^2. A produced part measures y=103. A note scales the $80 loss linearly by 3/4 and reports $60. Determine the correct loss.

Quality Industrial Systems Design Verification Root Cause Analysis Safe Correction
E-089
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

Loss was interpolated linearly from the calibration point.

What was missed

The Taguchi function squares the deviation from target.

Corrected model

Use L=k(y-T)^2 after determining k from the given loss condition.

QUICK ANSWER

From $80=k(4²), k=$5 per squared unit. At y=103 with target 100, deviation is 3, so L=5(3²)=$45.

ENGINEERING TAKEAWAY

Determine k from a known loss-deviation pair, then apply the quadratic Taguchi loss function L=k(y-T)^2.

CASE QUESTIONS

Questions this case should settle.

What is the Taguchi loss function?

L=k(y-T)^2 for the quadratic model used here.

What deviation keeps loss at or below $20 when k=5?

A deviation of 2 units or less.
