FE Mechanical Practice Question Solution included after investigation
CASE E-055 Β· FE

The 50 m Pipe That Lost 20 kPa

The velocity stayed at 2 m/s, yet wall friction consumed 20 kPa of pressure over the pipe length.

β–Ά INTERACTIVE CASE FILE β€’ 5–10 MIN β€’ CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-055 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field β€” in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

Water flows at 2.0 m/s through a 50 m long, 0.10 m diameter horizontal pipe. Use a Darcy friction factor f=0.020 and density 1000 kg/mΒ³. A review predicts no pressure drop because pipe diameter, velocity, and elevation are constant. Calculate the frictional pressure loss.

Fluid Mechanics Mechanical Design Verification Root Cause Analysis Safe Correction
E-055
INVESTIGATION WORKSPACE WORK THROUGH THE CASE β€” YOUR CHOICES MATTER.
πŸ”’
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

πŸ”’Root causeComplete the case
to reveal
πŸ”’Correct fixComplete the case
to reveal
πŸ”’Exam takeawayComplete the case
to reveal
CASE CLOSED Β· ENGINEERING VERDICT

What actually failed β€” and what should change.

What failed

An ideal-flow argument predicted zero pressure loss.

What was missed

Distributed wall friction.

Corrected model

Use Darcy-Weisbach loss with fL/D and dynamic pressure.

QUICK ANSWER

Darcy-Weisbach gives Ξ”P=f(L/D)(ρVΒ²/2). With f=0.02, L=50 m, D=0.10 m, ρ=1000 kg/mΒ³, and V=2 m/s, the pressure loss is 20,000 Pa, or 20 kPa.

ENGINEERING TAKEAWAY

Real internal flow requires a friction-loss term. Darcy-Weisbach scales loss with f, L/D, and dynamic pressure.

CASE QUESTIONS

Questions this case should settle.

Can pressure fall in a constant-diameter horizontal pipe?

Yes. Wall friction causes pressure loss even when average velocity and elevation are unchanged.

How does Darcy pressure loss scale with velocity?

Approximately with VΒ² when the other terms, including friction factor, are held fixed.
