FE Mechanical Practice Question Solution included after investigation
CASE E-054 Β· FE

The Fast-Looking Oil Flow That Was Still Laminar

The oil was moving at 2 m/s, but its Reynolds number was only 1700.

β–Ά INTERACTIVE CASE FILE β€’ 5–10 MIN β€’ CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-054 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field β€” in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

Oil flows through a 50 mm diameter pipe at 2.0 m/s. The oil density is 850 kg/mΒ³ and dynamic viscosity is 0.05 PaΒ·s. A technician labels the flow turbulent because 2 m/s seems fast. Calculate the Reynolds number, classify the flow, and determine what velocity would correspond to Re=4000 with the same oil and pipe.

Fluid Mechanics Mechanical Design Verification Root Cause Analysis Safe Correction
E-054
INVESTIGATION WORKSPACE WORK THROUGH THE CASE β€” YOUR CHOICES MATTER.
πŸ”’
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

πŸ”’Root causeComplete the case
to reveal
πŸ”’Correct fixComplete the case
to reveal
πŸ”’Exam takeawayComplete the case
to reveal
CASE CLOSED Β· ENGINEERING VERDICT

What actually failed β€” and what should change.

What failed

The flow was labeled turbulent from speed alone.

What was missed

Viscosity, density, and pipe diameter all affect the regime.

Corrected model

Use Re=ρVD/μ before classifying internal flow.

QUICK ANSWER

For ρ=850 kg/m³, V=2 m/s, D=0.05 m, and μ=0.05 Pa·s, Re=ρVD/μ=1700. The flow is therefore laminar under the usual internal-pipe-flow classification.

ENGINEERING TAKEAWAY

Pipe-flow regime depends on the dimensionless Reynolds number, not velocity alone.

CASE QUESTIONS

Questions this case should settle.

Can 2 m/s pipe flow be laminar?

Yes. Flow regime depends on Reynolds number, not velocity alone.

What velocity gives Re=4000 for this oil and pipe?

About 4.71 m/s.
