FE Chemical Practice Question Solution included after investigation
CASE E-062 · FE

The Evaporator That Removed 750 kg/h of Water

The feed was 1000 kg/h at 10 wt% solids. Concentrating to 40 wt% left only 250 kg/h liquid product.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-062 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

An evaporator receives 1000 kg/h of solution containing 10 wt% nonvolatile solids. Water is evaporated, and the liquid product contains 40 wt% solids. Assume no solids leave with the vapor. A quick estimate says the product flow is 400 kg/h because the product is 40% solids. Determine the actual liquid-product and vapor flow rates.

Material Energy Balances Chemical Design Verification Root Cause Analysis Safe Correction
E-062
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

Product composition was mistaken for a feed-flow fraction.

What was missed

Only 100 kg/h of nonvolatile solids enter.

Corrected model

Use the solids component balance, then the overall balance.

QUICK ANSWER

The feed contains 100 kg/h nonvolatile solids. At 40 wt% solids, product flow is 100/0.40=250 kg/h. The remaining 750 kg/h leaves as water vapor.

ENGINEERING TAKEAWAY

For a nonvolatile solute, balance the solute first; it fixes the concentrated-product flow.

CASE QUESTIONS

Questions this case should settle.

How do you solve an evaporator material balance with nonvolatile solids?

Balance the solids first, then use the overall mass balance for the vapor flow.

How much water is evaporated in this case?

750 kg/h.
