FE Chemical Practice Question Solution included after investigation
CASE E-063 · FE

The Heater That Needed 418 kW, Not 209

Heating the liquid required 209 kJ/kg. At 2 kg/s, that became 418 kW of heat transfer.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-063 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A liquid stream flows at 2.0 kg/s and is heated from 20°C to 70°C. Take cp=4.18 kJ/(kg·K), neglect phase change, kinetic and potential energy changes, and heat loss. A calculation finds cpΔT=209 kJ/kg and labels the heater duty 209 kW. Determine the correct heat-transfer rate.

Material Energy Balances Chemical Design Verification Root Cause Analysis Safe Correction
E-063
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

Specific sensible energy was reported as equipment power.

What was missed

Mass flow rate.

Corrected model

Use Qdot=m_dot cpΔT for the stated steady sensible-heating case.

QUICK ANSWER

The sensible-energy increase is cpΔT=4.18×50=209 kJ/kg. At 2 kg/s, the required heat-transfer rate is 2×209=418 kJ/s, or 418 kW.

ENGINEERING TAKEAWAY

Specific enthalpy or sensible-energy change must be multiplied by mass flow rate to obtain a steady energy rate.

CASE QUESTIONS

Questions this case should settle.

How do you calculate steady heater duty for sensible heating?

Use Qdot=m_dot cp(Tout-Tin) when cp is treated as constant and no phase change occurs.

Why is 209 kJ/kg not 209 kW?

kJ/kg is energy per unit mass; kW is energy per unit time.
