FE Mechanical Practice Question Solution included after investigation
CASE E-058 · FE

The Spring That Deflected 25.6 mm Under 500 N

The spring force was 500 N, but the deflection depended strongly on wire diameter, coil diameter, and active coils.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-058 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A helical compression spring has wire diameter 8 mm, mean coil diameter 64 mm, 8 active coils, and shear modulus G=80 GPa. It carries a 500 N load. A technician uses an arbitrary 50 N/mm stiffness. Determine the actual spring rate and deflection.

Mechanical Design Analysis Mechanical Design Verification Root Cause Analysis Safe Correction
E-058
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

A guessed spring rate was used.

What was missed

Wire diameter, coil diameter, active coils, and shear modulus determine k.

Corrected model

Compute k first, then use x=F/k.

QUICK ANSWER

For a helical compression spring, k=d⁴G/(8D³N). With d=8 mm, D=64 mm, N=8, and G=80 GPa, k≈19.53 N/mm. A 500 N load therefore causes about 25.6 mm deflection.

ENGINEERING TAKEAWAY

Calculate helical spring rate from geometry and shear modulus, then use F=kx.

CASE QUESTIONS

Questions this case should settle.

What is the helical compression spring rate formula?

k=d⁴G/(8D³N) for the idealized linear model.

What happens if active coil count increases?

Spring stiffness decreases.
