FE Other Disciplines Practice Question Solution included after investigation
CASE E-100 · FE

The Stronger Material That Made the Heavier Tie Rod

Material A had the higher yield strength, but its density penalty was much larger. After sizing both rods to the same factor of safety, Material B produced the lighter design.

▶ INTERACTIVE CASE FILE • 5–10 MIN • CLICK TO INVESTIGATE

Inspect, commit, prove, fix, and sign off.

Case E-100 engineering failure visual
HOW THIS WORKS

Think like
a real engineer.

Follow the investigation process used in the field — in five guided steps.

1

Inspect

Review the problem, diagram, and evidence.

2

Commit

Choose your hypothesis.

3

Prove

Run calculations and test your idea.

4

Fix

Select and validate a safe correction.

5

Sign Off

See the full debrief and key takeaways.

Case Brief

SAME PRINCIPLES. HIGHER STANDARDS.
PROBLEM STATEMENT

A 1.0 m tie rod must carry 60 kN in tension with factor of safety 2 against yielding. Material A has yield strength 300 MPa and density 7800 kg/m³. Material B has yield strength 240 MPa and density 2700 kg/m³. Neglect connection mass. Determine the minimum required area and mass for each material and select the lighter design.

Materials Other Disciplines Design Verification Root Cause Analysis Safe Correction
E-100
INVESTIGATION WORKSPACE WORK THROUGH THE CASE — YOUR CHOICES MATTER.
🔒
DEBRIEF (LOCKED)

Complete the investigation
to unlock the full debrief.

Find the root cause, confirm the fix, and see how this connects to the exam.

🔒Root causeComplete the case
to reveal
🔒Correct fixComplete the case
to reveal
🔒Exam takeawayComplete the case
to reveal
CASE CLOSED · ENGINEERING VERDICT

What actually failed — and what should change.

What failed

Highest yield strength was treated as the only selection criterion.

What was missed

Density strongly affects member mass.

Corrected model

Size by allowable stress, then compare rho A L or use strength-to-density as a screening metric.

QUICK ANSWER

With FS=2, Material A needs 400 mm² and has mass 3.12 kg. Material B needs 500 mm² but has mass only 1.35 kg, so B is the lighter strength-compliant choice.

ENGINEERING TAKEAWAY

For a tension member sized by allowable stress, mass is proportional to rho/sigma_allow, so strength and density must be considered together.

CASE QUESTIONS

Questions this case should settle.

What screening metric helps minimize mass in a strength-limited tie rod?

For common geometry and safety factor, maximize yield strength divided by density.
